ADAM-6250全新两年全国联保
ADAM-6250 |
支持Modbus TCP的15路隔离数字量I/O模块 |
?
?
| ? | ADAM-6250 | |
|---|---|---|
| ? |
?
|
|
| Digital Input | Input Voltage | Dry contact: Logic vel 0: close to GND Logic vel 1: open Wet contact: Logic vel 0: 0~ VDC max. Logic vel 1: 2~5 VDC |
| Channels | 8 | |
| Counter Input | 3kHz (32 bit + 1 bit overflow) | |
| Dry Contact | Logic 0: Open Logic 1: Closed to DGND | |
| Frequency Input Range | ~ 3kHz | |
| Input Impedance | kW (Wet Contact) | |
| Keep/Discard Counter Value when power off | - | |
| Supports Inverted DI Status | - | |
| Transition Time | ms | |
| Wet Contact | Logic 0: 0 ~ 3 VDC or 0 ~ -3 VDC Logic 1: 10 ~ 30 VDC or -10 ~ -30 VDC (Dry/Wet Contact decided by Switch) | |
| Digital Output | Channels | 7 (Sink Type) |
| Delay Output | High-to-Low and Low-to-High | |
| Normal Output Current | 100 mA (per channel) | |
| Output Voltage Range | 10 ~ 30 VDC | |
| Pulse Output | Up to 5kHz | |
| Environment | Humidity (Operating) | 20 ~ 95% RH (non-condensing) |
| Operating Temperature | -10 ~ 70°C (14 ~ 158°F) | |
| Storage Humidity | 0 ~ 95% RH (non-condensing) | |
| Storage Temperature | -20 ~ 80°C (-4 ~ 176°F) | |
| General | Connector | Plug-in 5P/15P screw terminal blocks |
| Dimensions | 110 x 60 x 27 mm | |
| Ethernet | 2-port 10/100 Base-TX (for Daisy Chain) | |
| D Indicators | 8 DI + 7 DO | |
| Power Consumption | 3 W @ 24 VDC | |
| Power Input | 10 - 30 VDC (24 VDC standard) | |
| Protection | Built-in TVS/ESD protection Power Reversal protection Over Voltage protection: +/- 35VDC Isolation protection: 2500 VDC | |
| Protocol | Modbus/TCP, TCP/IP, UDP, HTTP, DHCP | |
| Watchdog Timer | System ( seconds), Communication (Programmab) | |
| 产品描述 | ? | |
|---|---|---|
| ? | ? | ? |
| ADAM-6250-B? ? ? ? CIRCUIT BOARD, 15-ch Isolated Digital I/O Modbus TCP Modu | ? |
